Jual Rocket M5 + AirMax-5G20-90 - UBIQUITI UBNT

Rocket M5 + AirMax-5G20-90

Spesifikasi dan Harga Jual - DataSheet - Ubiquiti UBNT - Rocket M5 + AirMax-5G20-90 baru murah bergaransi.

Packet Basestation Rocket M5 dan gabungan dari  AirMax-5G20-90, 5 GHz, 20dBi memungkinkan perangkat sebagai mode station yang baik di kondisi lapangan dengan Band 5 Ghz perangkat bisa di gunakan untuk membuat LINK Point to Point 40-50Km dengan mudah.
gabungan  AirMax-5G20-90, 5 GHz, 20dBi dengan Rocket M5 sebagai pengembangan perangkat yang Comfortable.

Product specification

Specifications  Rocket M 5

Details
Product code	UBNT - Rocket M 5 + AirMax-5G20-90, 5 GHz, 20dBi, 90 deg
Networking Interface	1 X 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet
CPU core count	Atheros MIPS 24KC, 400MHz
Architecture	UBNT
Size of RAM	64MB SDRAM, 8MB Flash
Wireless Approvals	FCC Part 15.247, IC RS210, CE
RoHS Compliance	YES
Enclosure Characteristics	Outdoor UV Stabilized Plastic
Mounting Kit	Pole Mounting Kit included
Power Supply	24V, 1A POE Supply included
Power Method	Passive Power over Ethernet (pairs 4, 5+; 7, 8 return)
Operating Temperature	-30C to 75C
Operating Humidity	5 to 95% Condensing
Shock and Vibration	ETSI300-019-1.4
RF Connector	2x RP-SMA (Waterproof)
Max Power Consumption	8 Watts
Compatible Antennas	AirMax Sector 5G-17-90 5G-16-120 5G-20-90 5G-19-120,   Rocket Dish 5G-30 5G-34
Operating Frequency Summary (MHz)	5470-5825*
Link PTP	40-50 Km

Specifications   AirMax-5G20-90, 5 GHz, 20dBi, 90 deg

Frequency Range	5.15 - 5.85 GHz
Gain	19.4 - 20.3 dBi
HPOL Beamwidth	91° (6 dB)
Architecture	UBNT
Dimensions	700 x 135 x 70 mm
Weight	5.9 kg (Mount Included)
Wind Survivability	125 mph
ETSI Specification	EN 302 326 DN2
Mounting Kit	Universal Pole Mount, Rocket Bracket, and Weatherproof RF Jumpers Included
Cross-pol Isolation	28 dB Min
Polarization	Dual Linear
Wind Loading	41 lbf @ 125 mph
